Be part of us to find how the brand new ZEISS Crossbeam 750 with its see when you mill functionality delivers precision and readability—each time—for demanding FIB-SEM workflows. Designed for very difficult TEM lamella preparation, tomography, superior nanofabrication, and APT‑prepared elevate‑out, Crossbeam 750 combines a brand new Gemini 4 SEM goal lens, a double deflector, and a subsequent‑technology scan generator to raise each picture high quality and course of confidence. You’ll find out how higher decision and higher SNR translate into extra picture element and shorter acquisition instances, whereas the low‑kV FIB efficiency allows extra exact lamella prep.
We’ll show Excessive Dynamic Vary (HDR) Mill + SEM—an interwoven SEM/FIB scanning mode that suppresses FIB‑generated background. This allows fast, clear visible suggestions, even throughout nudging the FIB sample dwell whereas milling . The consequence: assured endpointing with uninterrupted FIB milling and pristine, metrology‑grade surfaces with the bottom potential pattern harm.
This session is right for semiconductor failure analysists, yield groups and supplies scientists searching for quicker time‑to‑TEM, increased first‑cross success, and constant outcomes at low kV. See how Crossbeam 750 empowers you to make earlier cease‑milling selections, lower rework, and reliably plan turnaround time—so you’ll be able to transfer from pattern to perception with confidence.
