A Nineteen Eighties-era semiconductor fab in Austin, Texas, is getting a makeover. The Texas Institute for Electronics (TIE), because it’s referred to as now, is tooling as much as change into the one superior packaging plant on the planet that’s devoted to 3D heterogenous integration (3DHI)—the stacking of chips made from a number of supplies, each silicon and non-silicon.
The fab is the infrastructure behind DARPA’s Next-Generation Microelectronics Manufacturing (NGMM) program. “NGMM is targeted on a revolution in microelectronics by 3D heterogeneous integration,” mentioned Michael Holmes, managing director of this system.
Stacking two or extra silicon chips inside the identical bundle makes them act as if they’re all one built-in circuit. It already powers a few of the most advanced processors on the planet. However DARPA predicts silicon-on-silicon stacking will lead to not more than a 30-fold enhance in efficiency over what’s potential with 2D integration. In contrast, doing it with a mixture of supplies—gallium nitride, silicon carbide, and different semiconductors—might ship a 100-fold enhance, Holmes advised engineers and different events on the program’s unofficial popping out occasion, the NGMM Summit, late final month.
The brand new fab will make certain these uncommon stacked chips are prototyped and manufactured in the USA. Startups, and there have been many on the launch occasion, are in search of a spot to prototype and start manufacturing concepts which might be too bizarre for wherever else—and hopefully bypassing the lab-to-fab valley of loss of life that claims many {hardware} startups.
The state of Texas is contributing $552 million to face up the fab and its packages, with DARPA contributing the remaining $840 million. After NGMM’s five-year mission is full, the fab is anticipated to be a self-sustaining enterprise. “We’re, frankly, a startup,” mentioned TIE CEO Dwayne LaBrake. “We’ve got extra runway than a typical startup, however we have now to face on our personal.”
Beginning up a 3DHI Fab
Attending to that time will take lots of work, however the TIE foundry is off to a fast begin. On a tour of the ability, IEEE Spectrum noticed a number of chip manufacturing and testing instruments in varied states of set up and met a number of engineers and technicians who had began inside the final three months. TIE expects all of the fab’s instruments to be in place within the first quarter of 2026.
Simply as necessary because the instruments themselves is the flexibility of foundry clients to make use of them in a predictable manufacturing course of. That’s one thing that’s notably tough to develop, TIE officers defined. On the most simple stage, non-silicon wafers are typically not the identical measurement as one another. And so they have totally different mechanical properties, that means they develop and contract with temperature at totally different charges. But a lot of the fab’s work can be linking these chips along with micrometer precision.
The primary part of getting that finished is the event of what are referred to as a course of design equipment and an meeting design equipment. The previous offers the foundations that constrain semiconductor design on the fab. The latter, the meeting design equipment, is the actual coronary heart of issues, as a result of it offers the foundations for the 3D assembly and other advanced packaging.
Subsequent, TIE will refine these by the use of three 3DHI initiatives, which NGMM is looking exemplars. These are a phased-array radar, an infrared imager referred to as a focal airplane array, and a compact energy converter. Piloting these by manufacturing “offers us an preliminary roadmap… an on-ramp into large innovation throughout a broader software house,” mentioned Holmes.
These three very totally different merchandise are emblematic of how the fab should function as soon as it’s up and operating. Executives described it as a “high-mix, low-volume” foundry, that means it’s going to must be good at doing many various issues, nevertheless it’s not going to make lots of anyone factor.
That is the other of most silicon foundries. A high-volume silicon foundry will get to run a lot of related check wafers by its course of to work out the bugs. However TIE can’t try this, so as an alternative it’s counting on AI—developed by Austin startup Sandbox Semiconductor—to assist predict the result of tweaks to its processes.
Alongside the best way, NGMM will present a lot of analysis alternatives. “What we have now with NGMM is a really uncommon alternative,” mentioned Ted Moise, a professor at UT Dallas and an IEEE Fellow. With NGMM, universities are planning to work on new thermal conductivity movies, microfluidic cooling know-how, understanding failure mechanisms in advanced packages, and extra.
“NGMM is a bizarre program for DARPA,” admitted Whitney Mason, director of the company’s Microsystems Expertise Workplace. “It’s not our behavior to face up amenities that do manufacturing.”
However “Preserve Austin Bizarre” is town’s unofficial motto, so possibly NGMM and TIE will show an ideal match.
